Servo & Stepper Motor Controller-C5-E-2-11

Ethernet / ip Motor Controller-C5-E-2-11, designed based on standard Ethernet / ip protocol, can drive stepper motors, stepper motors with encoders, DC servo motors (EC servos), etc. Rated current output 0-10A (command adjustment), peak current (0-30A) (command adjustment). Applicable to equipment application of AB master station.

Features

Ethernet / ip Motor Controller
Stepper & EC?servo?Universal
Rated current output 0-10A?
peak current (0-30A)
Easy to control via Ethernet / ip?or USB
Compact
Integrated input and output module

規(guī)格參數(shù)

額定電流（A）:	10 A
供電電壓 V DC:	12-48 V DC
控制接口:	EtherNet/IP
輸入 & 輸出:	5?Digital inputs (5V/24V ) 2? Analog input 0-10 V, 0-20 mA/0-10 V switchable? 3?Digital outputs
OEM可編程:	Yes
定制化:	Firmware
適用電機(jī):	stepper and DC servo motor
